Hoshizaki FM-80KE-HC Flake Ice Maker – Self-Contained Commercial Ice Machine

Spec Sheet

The Hoshizaki FM-80KE-HC Flake Ice Maker is a compact, self-contained commercial ice machine designed to produce up to 85 kg of high-quality flake ice per 24 hours under standard conditions (air temperature 10°C, water temperature 10°C). This model is ideal for restaurants, cafés, hotels, supermarkets, fish displays, food preparation areas, and healthcare environments where reliable flake ice production is essential.

Flake ice provides fast cooling and excellent product coverage, making it suitable for food display, preservation, and preparation. The FM-80KE-HC incorporates Hoshizaki’s proven CleanCycle6 system, which automatically rinses built-up mineral impurities every 6 hours, ensuring consistent ice quality while reducing maintenance requirements. Water consumption is equal to ice production, offering predictable and efficient water usage.

Hygiene is further enhanced through an automatic rinse cycle and a closed water circuit, which protects against contamination throughout the ice-making process. The machine features an electronic controller for reliable operation and includes an operation time-based parts replacement system to support preventive maintenance planning.

The auger is constructed from double-hardened stainless steel, ensuring durability and long service life. Carbon graphite bushings allow the machine to operate without grease, minimizing wear and reducing maintenance costs. Additional user-friendly features include a cleanable air filter and a removable door gasket for easy routine cleaning and servicing.

FM-series machines can be converted to produce flake or nugget ice by a qualified engineer, providing flexibility to meet changing operational requirements.

Technical Specifications

• Model: FM-80KE-HC

• Ice type: Flake ice (convertible to nugget ice by qualified engineer)

• Cooling system: Air cooled

• Ice production capacity:

  • 85 kg / 24h at AT 10°C, WT 10°C

  • 75 kg / 24h at AT 21°C, WT 15°C

  • 60 kg / 24h at AT 32°C, WT 21°C

• Power supply: 1 / 220–240V / 50Hz

• Electrical circuit breaker protection: 6 A

• Heat rejection: 0.45 kW (AT 32°C, WT 21°C)

• Water consumption: 0.085 m³ / 24h (AT 10°C, WT 10°C)

Key Features

• Self-contained flake ice maker

• CleanCycle6 system for automatic mineral rinse every 6 hours

• Water consumption equal to ice production

• Automatic rinse cycle

• Closed water circuit for contamination protection

• Electronic controller

• Time-based parts replacement system for preventive maintenance

• Double-hardened stainless steel auger

• Carbon graphite bushings for grease-free operation

• Cleanable air filter

• Removable door gasket

• Convertible to flake or nugget ice by qualified engineer

Dimensions & Shipping Specifications

• Net dimensions (W × D × H, legs excluded): 640 × 600 × 711 mm

• Legs height: additional 87–122 mm

• Net weight: 65 kg

• Packed dimensions (W × D × H): 746 × 706 × 887 mm

• Gross packed weight: 75 kg

• Packed volume: 0.467 m³
